Telpix TVST-PVT-4M04 PVT-4M Series | 4 Channel 4MP/1080P Penta-brid(TVI / AHD / CVI / IP / 960H) DVR System, 1 x SATA

Additional View

Telpix TVST-PVT-4M04 PVT-4M Series | 4 Channel 4MP/1080P Penta-brid(TVI / AHD / CVI / IP / 960H) DVR System, 1 x SATA

Model	TVST-PVT-4M04
Video
Camera input	4 BNC
Individual HD/Analog selectable	Analog, AHD, TVI, CVI
Available source	TVI 720p25,30/1080p25,30/3MP@18 ~ 30/4MP@12 ~ 30 AHD 720p25,30/1080p25,30/3MP@18 ~ 30/4MP@12 ~ 30 Composite/960H/Mixed
IP Camera Spec	ONVIF 2.3, RTSP, H.264, dual stream use gigabit ethnet hub
IP Camera Num	2
IP Camera Restriction	Cannot setup Private ZONE Cannot support Timestamp
Output	1 HDMI (Main Display, ~1080p60) 1 VGA (Main Display, ~1080p60) 1 Composite (Programmable SPOT)
Audio/Alarm & Sensor
Audio input	4 RCA
Output	1 RCA
Sensor In	4 (NC, NO selectable)
Alarm out	1 relay
Operating System	Embedded Linux OS
Display
Speed	Real Time
Resolution (Pixel)	1280 � 1024, 1280 � 720, 1920 � 1080
Split screen	1,4
Main Recording
CODEC	H.264
Resolution (Pixel)	4MP, 720p (4MP@12 ~ 30) 3MP, 720p (3MP@18 ~ 30) 1080p, 720p (1080p@25,30) 720p, 960 � 540 (720p#25,30) 960H, D1(Composite, 960H)
Picture quality	4 steps (Super, High, Medium, Low)
Speed	60fps @ 4MP
Dual Recording
CODEC	H.264
Resolution (Pixel)	N/A
Playback
Display	1,4
Search mode	Calendar, Event ,POS , Panorama, Thumbnail
Speed	30fps @ 4MP
Fast/Slow speed	Normal, REW & FF [recorded speed � 2, � 4, � 8, � 16,x32,x64,x1/2,x1/4], Frame to frame, Pause
Network(Individual setting of resolution, frame rates and picture quality)
Network Interface	Megabit Ethernet
High Resolution (Pixel)	1080p, 720p(4MP@12 ~ 30) 1080p, 720p(4MP@12 ~ 30) 1080p, 720p(1080p25,30) 720p, 960 � 540 (720p25,30) 960H, D1 (Composite, 960H)
Low Resolution (Pixel)	480 � 256 (4MP, 3MP, 1080p, 720p) CIF (Composite, 960H)
Speed	40fps @ 1080p
Protocol	TCP/IP, HTTP, DHCP
Application	Windows 7 / 8 / 10 (PC Client system& IE)/MAC
Web Browser	Internet Explorer, Safari, Chrome, Firefox
Smart phone App	Android, iPhone for live and search
Backup
Interface	USB 2.0 � 2
Backup device	External HDD, CD&DVD-RW, Network, Thumb Drive
The number of HDD	1 SATA(No capacity limit ; 6TB of more)
Function
	Full GUI with alpha blending
	Individual setting of resolution, frame rates and picture quality
	Instant Replay
	Digital Zoom
	Mouse Control
	Weekly scheduler with holiday by 10 minutes setting
	Covert, Disable and Private function of cameras
	Motion Detection with 576 area setting
	Relay alarm output
	PTZ control by RS-485
	Daylight Saving Time and Network Time Setting
	Multi User Authority up to 8 Users
	Deinterlacer upon live and playback
	22 languages with full graphic
	Individual Network port setting
	Auto Deletion
	Import and Export the configuration
	Interactive setup via network
	POS Interface
	Mirroring
	Dual CODEC engine for independent video transmission
Others
Power Consumption	24W
Operating Temperature	5 ~ 40�C(41 ~ 104F)
Relative Humidity	Maximum 80% non-condensing
Dimension	300(W) � 210(D) � 48(H) mm
