Telpix TVST-PVT-16N PVT-N Series|16 Channel 3MP/1080P Quad-brid DVR System

Additional View

Telpix TVST-PVT-16N PVT-N Series|16 Channel 3MP/1080P Quad-brid DVR System

Model	TVST-PVT-16N
Video
Camera input	16 BNC
Individual HD/Analog selectable	Analog, AHD, TVI
Available source	TVI 720p25,30/1080p25,30/3MP@18 AHD 720p25,30/1080p25,30 Composite/960H/Mixed
IP Camera Spec	ONVIF 2.3, RTSP, H.264, dual stream use gigabit ethnet hub
IP Camera Num	4
IP Camera Restriction	Cannot setup Private ZONE Cannot support Timestamp
Output	1 HDMI (Main Display) 1 VGA (Main Display) 1 Composite (Programmable SPOT)
Audio/Alarm & Sensor
Audio input	16 ( 8 RCA + 8 DB15)
Output	1 RCA
Sensor In	16 (NC, NO selectable)
Alarm out	1 relay
Operating System	Embedded Linux OS
Display
Speed	Real Time
Resolution (Pixel)	1280�1024, 1280�720, 1920�1080
Split screen	1,4,6,8,9,13,16
Main Recording
Resolution (Pixel)	3MP, 720p (3MP@18) 1080p, 720p (1080p@25,30) 720p, 960�540 (720p@25,30) 960H, D1(Composite, 960H)
Picture quality	4 steps (Super, High, Medium, Low)
Speed	240fps @ 1080p
Dual Recording
Resolution (Pixel)	480�256
Playback
Display	1,4,6,8,9,13,16
Search mode	Calendar, Event ,POS , Panorama, Thumbnail
Speed	240fps
Fast/Slow speed	Normal, REW & FF [recorded speed �2, �4, �8, �16,�32,�64,�1/2,�1/4], Frame to frame, Pause
Network(Individual setting of resolution, frame rates and picture quality)
Network Interface	Gigabit Ethernet
High Resolution (Pixel)	1080p, 720p(4MP@12 ~ 30) 1080p, 720p(4MP@12 ~ 30) 1080p, 720p(1080p25,30) 720p, 960 � 540 (720p25,30) 960H, D1 (Composite, 960H)
Speed	80fps @ 1080p
Protocol	TCP/IP, HTTP, DHCP
Application	Windows 7 / 8 / 10 (PC Client system& IE)/MAC
Web Browser	Internet Explorer, Safari, Chrome, Firefox
Smart phone App	Android, iPhone for live and search
Backup
Interface	USB 2.0 � 2
Backup device	External HDD, CD&DVD-RW, Network, Thumb Drive
The number of HDD	2 SATA(No capacity limit ; 6TB of more)
Function
	Full GUI with alpha blending
	Individual setting of resolution, frame rates and picture quality
	Instant Replay
	Digital Zoom
	Mouse Control
	Weekly scheduler with holiday by 10 minutes setting
	Covert, Disable and Private function of cameras
	Motion Detection with 576 area setting
	Relay alarm output
	PTZ control by RS-485
	Daylight Saving Time and Network Time Setting
	Multi User Authority up to 8 Users
	Deinterlacer upon live and playback
	22 languages with full graphic
	Individual Network port setting
	Auto Deletion
	Import and Export the configuration
	Interactive setup via network
	POS Interface
	Mirroring
	Dual CODEC engine for independent video transmission
Others
Power Consumption	60W
Operating Temperature	5 ~ 40�C(41 ~ 104F)
Relative Humidity	Maximum 80% non-condensing
Dimension	380(W)�340(D)�50(H)mm
