Telpix TVST-AR324-8 AR324 Series | H.265+ 8 Channel 4MP/3MP/1080P Penta-brid DVR System, P2P EZ Setup, 1xSATA

Additional View

Telpix TVST-AR324-8 AR324 Series | H.265+ 8 Channel 4MP/3MP/1080P Penta-brid DVR System, P2P EZ Setup, 1xSATA

Model	TVST-AR324-8
Video compression	H.264/H.264+ /H.265/H.265+
Analog, AHD, HD-TVI and HD-CVI video input	8 Ch., BNC interface (1.0Vp-p, 75O)
HDTVI Input	"3 MP, 1080p, 720p Note: The 3 MP signal input is only available for channel 1/2"
AHD Input	1080p, 720p
HDCVI Input	1080p, 720p
CVBS Input	PAL/NTSC
IP Video Input	2CH, Up to 4MP Resolution/Supports H.265+/H.265/H.264+/H.264 IP cameras
Audio compression	G.711u
Audio input/Two-way audio in	1-ch, RCA (2.0 Vp-p, 1 KO)
Video Output	1 HDMI, 1 VGA, 1 CVBS
CVBS Output	1-ch, BNC (1.0 Vp-p, 75 O), resolution: PAL: 704 � 576, NTSC: 704 � 480
VGA output	1920 � 1080@60Hz, 1280 � 1024@60Hz, 1280 � 720@60Hz, 1024 � 768@60Hz
HDMI output	1920 � 1080@60Hz, 1280 � 1024@60Hz, 1280 � 720@60Hz, 1024 � 768@60Hz
Encoding resolution	When 1080p Lite mode not enabled: 3 MP/1080p/720p/VGA/WD1/4CIF/CIFWhen 1080p Lite mode enabled: 3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF
Frame rate	"Main stream: When 1080p Lite mode not enabled: For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fpsFor 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)@30fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)@30fps (N) When 1080p Lite mode enabled: 3 MP@15fps 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)@30fps (N) Sub-stream: When 1080p Lite mode not enabled: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)"
Video bitrate	32 Kbps to 6 Mbps
Audio output	1 Ch., RCA (Linear, 1KO)
Audio bitrate	64 Kbps
Dual-stream	Support
Stream type	Video & Audio
Synchronous playback	8 Ch.
Playback resolution	1080P/720P/VGA/WD1/4CIF/CIF/QVGA/QCIF
Remote connections	128
Network protocols	TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP�, HTTPS, ONVIF
SATA	1 SATA interface
Capacity	Up to 10TB capacity
Network interface	1; 10M/100M self-adaptive Ethernet interface
Serial interface	1 x RS-485 serial interface
USB port	2 � USB2.0
Power supply	12 VDC
Consumption (without hard disks)	= 7.5W
Working temperature	-10 �C ~ +55 �C (14 �F ~ 131 �F)
Working humidity	10% ~ 90%
Dimensions	315 � 242 � 45 mm (12.4 � 9.5 � 1.8 inch)
Weight (without hard disks)	3.9 lb
