IP Power NVST-TS5416-16E TS series 5416-16E | 16Ch Network Video Recorder (NVR), 16 PoE port, H.265, up to 8MP (4K), HDMI, 112Mbps Bandwidth, 8 × SATA, 1 × eSATA

Additional View

IP Power NVST-TS5416-16E TS series 5416-16E | 16Ch Network Video Recorder (NVR), 16 PoE port, H.265, up to 8MP (4K), HDMI, 112Mbps Bandwidth, 8 × SATA, 1 × eSATA

SKU#

:

NVST-TS5416-16E

Availability

:

Usually ships the next business day

Hard Drive

:

Warranty

:

Hi-Res Security Monitor

:

Quantity

:

Description
Features
Specifications
Downloads
Product Review

IP Power NVST-TS5416-16E TS series 5416-16E | 16Ch Network Video Recorder (NVR), 16 PoE port, H.265, up to 8MP (4K), HDMI, 112Mbps Bandwidth, 8 × SATA, 1 × eSATA

Support 16 CH 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P IP input
Adopt standard H.265 and H.264 high profile compression format to get high-quality video at much lower bit rate
Intuitive and user-friendly Graphic User Interface ( GUI ), Windows style operation by mouse
Multi-mode recording: manual / timer / motion / sensor
Playback : 16 CH simultaneous playback
Search : time slice, time, event ( manual, sensor, motion ), tag search
Express and flexible backup via USB, network and so on
Pentaplex : preview, record, playback, backup and remote access
DHCP, DDNS, PPPoE network protocol and CMS supported
Remote control via IE or CMS : preview, playback, backup, PTZ and configuration
16 PoE network ports, support IPC direct connection to NVR; support PoE power supply
Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
Multi-user online simultaneously
Authorization management, log view and device status view
4K output, true high resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
Support NAT function and QRCode scanning by mobile phone and PAD
Powerful smart phone & Pad surveillance with iOS and Andriod OS

Model	NVST-TS5416-16E
System
Compression	Standard H.265, H.264
OS	Embedded Linux
Video
Network Input	16 CH IPC input
Network Access Bandwidth	112Mbps
Network Access Format	8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P@25 / 30fps
Output	HDMI × 1 : 3840 × 2160 / 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
Audio
Network Input	16 CH IPC audio input
2-way Audio	RCA × 1
Local Output	RCA × 1
Record
Record Stream	Dual stream recording
Resolution	8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P
Mode	Manual, timer, motion, sensor
Playback
Simultaneous Playback	Max 16 CH
Search	Time slice / time / event / tag search
Smart Search	Highlighted color to display the camera record in a certain period of time, different colors refers to different record events
Function	Play, pause, FF, FB, digital zoom, etc.
Alarm
Mode	Manual, sensor, motion, exception
Input	Support IPC alarm input
Output	Support IPC alarm output
Triggering	Record, snap, preset, e-mail, etc.
Network
Interface	RJ45 10 / 100 / 1000 Mbps × 1
PoE Port	RJ45 × 16
Protocol	TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP
Mobile Device
OS	iOS, Andriod
Storage
HDD	SATA × 2, max 8T per HDD
Backup
Local Backup	U disk, USB mobile HDD
Network Backup	Yes
Port
USB	USB 2.0 × 2 ( one in the front panel and the other in the rear panel )
Remote Controller	Optional
Others
Power Supply	DC48V
Consumption	≤ 15W ( without HDD )
Dimensions (mm)	380 × 268 × 52 ( W × D × H )
Work Environment	-10 ~ 50°C, 10% ~ 90% humidity
