IP Power NVST-NRA10-32 NR series NRA10-32 | 32Ch Network Video Recorder (NVR), H.265, up to 12MP, HDMI, 320Mbps Bandwidth, 8 × SATA, 1 × eSATA

Additional View

IP Power NVST-NRA10-32 NR series NRA10-32 | 32Ch Network Video Recorder (NVR), H.265, up to 12MP, HDMI, 320Mbps Bandwidth, 8 × SATA, 1 × eSATA

SKU#

:

NVST-NRA10-32

Availability

:

Usually ships the next business day

Hard Drive

:

Warranty

:

Hi-Res Security Monitor

:

Quantity

:

Description
Features
Specifications
Downloads
Product Review

IP Power NVST-NRA10-32 NR series NRA10-32 | 32Ch Network Video Recorder (NVR), H.265, up to 12MP, HDMI, 320Mbps Bandwidth, 8 × SATA, 1 × eSATA

4K Network Video Recorder
32CH IP Video
H.265, H.264+, H.264 Video Formats
3rd Party Network Cameras Supported
Up To 12MP Resolution Recording
Up To 320 Mbps Incoming Bandwidth
8 SATA Interfaces Up To 6TB Each HDD
2 HDMI, 2 VGA Outputs

Model	NVST-NRA10-32
Video/Audio input
IP Video Input	32-ch Up to 12 MP resolution
Network(NVR)
Incoming bandwidth	320 Mbps, or 200 Mbps (when RAID is enabled)
Outgoing bandwidth	256 Mbps, or 200 Mbps (when RAID is enabled)
Remote Connections	128
Video/Audio output
Recording resolution	12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
HDMI output resolution	HDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA output resolution	VGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz VGA2 /HDMI2 output resolution :1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio output(video recorder)	2-ch, RCA (2.0Vp-p, 1 KO)
Decoding
Decoding format	H.265/H.264/MPEG4
Live View / Playback Resolution	12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous Playback	16-ch
Capability	4-ch @4K, or 16-ch @ 1080p
Hard disk
SATA	8 SATA interfaces for 8HDDs
eSATA (optional)	1 eSATA interface
Capacity	Up to 6TB capacity for each HDD
Disk array
Array type	RAID0, RAID1, RAID5, RAID10
Number of arrays	4
External Interface
Two-way audio	1-ch, RCA (2.0 Vp-p, 1kΩ)
Network interface (video recorder)	2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Serial Interface	RS-232; RS-485; Keyboard
USB Interface	Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm in/out	16/4
Electrical
Power	200 W
Construction
Dimensions	445 × 470 ×90 mm (17.5"× 18.5" × 3.5")
General
Power Supply	100 to 240 VAC, 50 to 60 Hz
Power	200 W
Consumption (without hard disks)	=30 W
Dimensions	445 × 470 ×90 mm (17.5"× 18.5" × 3.5")
Weight	≤ 10 Kg (22 lb)
Chassis	19-inch rack-mounted 2U chassis
Working temperature (video recorder)	-10 to +55ºC (14 to 131ºF)
Working humidity (video recorder)	10 to 90 %
