LTS LTN8964-8 Platinum Enterprise Level 64 Channel NVR

Additional View

LTS LTN8964-8 Platinum Enterprise Level 64 Channel NVR

SKU#

:

LTN8964-8

Regular Price

:

$1899.95

Sale Price

:

$1699.95

You Save

$200.00(10.53% )

Availability

:

Usually ships the next business day

Hard Drive

:

Warranty

:

Hi-Res Security Monitor

:

Quantity

:

LTS LTN8964-8 Platinum Enterprise Level 64 Channel NVR

Model	LTN8964-8
Video/Audio input
IP video input	64-ch Up to 12 MP resolution
Two-way audio	1-ch, RCA (2.0 Vp-p, 1 k Ω)
Network
Incoming bandwidth	320 Mbps or 200 Mbps (when RAID is enabled)
Outgoing bandwidth	256 Mbps, or 200 Mbps (when RAID is enabled)
Remote connection	128
Video/Audio output
Recording resolution	12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
CVBS output (Optional)	1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 � 576, NTSC: 704 � 480
VGA1 /HDMI1 output resolution	HDMI1: 4K (3840 � 2160)/60Hz, 4K (3840 � 2160)/30Hz, 2K (2560 � 1440)/60Hz, 1920 � 1080p/60Hz, 1600 � 1200/60Hz, 1280 � 1024/60Hz, 1280 � 720/60Hz, 1024 � 768/60Hz VGA1: 2K (2560 � 1440)/60Hz, 1920 � 1080p/60Hz, 1600 � 1200/60Hz, 1280 � 1024/60Hz, 1280 � 720/60Hz, 1024 � 768/60Hz
VGA2 /HDMI2 output resolution	1920 � 1080p/60Hz, 1280 � 1024/60Hz, 1280 � 720/60Hz, 1024 � 768/60Hz
Audio output	2-ch, RCA (2.0Vp-p, 1 KΩ)
Decoding
Decoding format	H.265+/H.265/H.264/H.264+/MPEG4
Live view/Playback resolution	12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous playback	16-ch
Capability	2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP (30fps) / 16-ch @ 1080p (30fps)
Network management
Network protocols	TCP/IP, DHCP, LTS-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP�, HTTPS
Hard disk
SATA	8 SATA interfaces for 8HDDs
eSATA	1 eSATA interface
Capacity	Up to 10TB capacity for each HDD
Disk array
Array type	RAID0, RAID1, RAID5, RAID6, RAID10
Number of arrays	4
External interface
Network interface	2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Serial interface	RS-232; RS-485; Keyboard
USB interface	Front panel: 2 � USB 2.0; Rear panel: 1 � USB 3.0
Alarm in/out	16/4
General
Power supply	100 to 240 VAC, 50 to 60 Hz
Max. Power	200 W
Consumption (without HDD)	≤ 30 W
Working temperature	-10 �C to 55 �C (14 �F to 131 �F)
Working humidity	10 to 90 %
Dimensions(W � D � H)	445 � 470 �90 mm (17.5"� 18.5" � 3.5")
Weight (without HDD)	≤ 8 kg (17.6 lb)
