LTS LTN07256-R Platinum Enterprise Level 256 Channel NVR 3U
LTS LTN07256-R Platinum Enterprise Level 256 Channel NVR 3U
- 256 Channel Network Video Recorder
- Video Input: 256CH IP@640Mbps
- Video Output: VGA/HDMI up to 1920x1080P
- Pentaplex Operation: Record, Playback, Backup, Live & Remote Access
- Recording Resolution: Up to 8MP (4096x2304)
- Recording Mode: Manual, Schedule, Video Detection, Motion Detection, Video Loss, Stop
- Playback Channel: 16CH
- Playback Resolution: Up to 8MP (4096x2304)
- Audio In/Out: 1CH/ 1CH, RCA
- Alarm In/Out: 16/8
- Network: 10/100/1000M, 4xRJ45
- Storage: 16 SATA up to 128TB, RAID
- 2 USB 2.0 + 2 USB 3.0, NAS, IP SAN
- Backup: USB, NAS, or eSATA, DVD-RW
Model | LTN07256-R |
Recorder Series | Platinum Series |
Recorder Channel | Others |
Recorder Case | 3U Case |
Recorder Technology | IP / NVR |
Featured Product | No | Video/Audio Input |
IP Video Input | 256-CH,Up to 8MP Resolution |
Two-Way audio Input | 1-ch, RCA (2.0 Vp-p, 1kΩ) | Network |
Incoming Bandwidth | 640Mbps, or 400Mbps (When RAID is Enabled) |
Outgoing Bandwidth | 400Mbps |
Remote Connection | 256 | Video/Audio Output |
Recording Resolution | 8MP/6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
HDMI1/VGA1 Output Resolution | 1-ch, 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768/60Hz |
HDMI2 Output | 1-ch, 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768/60Hz |
HDMI outputs (on HDMI Output Extension Board) | 1-ch, 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768/60Hz |
Audio Output | 1-ch, RCA (Linear, 1kΩ) | Decoding |
Live View/Playback Resolution | H.264, MPEG4, M-JPEG |
Synchronous Playback | 16-CH |
Capability | 44-ch@1080P | Hard Disk |
SATA | 16 SATA Interfaces for 16HDDs |
Capacity | Up to 8TB Capacity for Each HDD | Disk Array |
Array Type | RAID0, RAID1, RAID5, RAID10 |
Number of Array | 16 | Interface |
Network Interface | 4 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet Interfaces |
Optic Fiber Interface | 4, 1000 Mbps Optic Fiber Interface |
Serial Interface | RS-232; RS-485; Keyboard |
USB Interface | 2 × USB 2.0 on Front Panel and 2 × USB 3.0 on Rear Panel |
Alarm In/Out | 16/8 | General |
Power Supply | 100 ~ 240 VAC, 50 ~ 60 Hz |
Consumption | ≤ 100 W (Without Hard Disk or DVD-R/W) |
Working Temperature | 14ºF ~ 131ºF(-10 ºC ~ +55 ºC) |
Working Humidity | 10% ~ 90% |
Casing | 19-Inch Rack-Mounted 3U Chassis |
Dimensions (WxDxH) | 17.4" ×19.4"×5.7"(442× 494 ×146 mm) |
Weight | ≤ 34.2 lb (15.5 Kg,without hard disk or DVD-R/W) |
