LTS CMIP3142W-28SWIFI Platinum Network Mini Wifi Dome IP Camera 4.1MP

Additional View

LTS CMIP3142W-28SWIFI Platinum Network Mini Wifi Dome IP Camera 4.1MP

Model	CMIP3142W-28SWIFI
Camera Series	Platinum Series
Camera Resolution	4.1MP
Camera Technology	IP / Network
Camera Housing	Dome
Featured Product	No
Camera
Image Sensor	1/3" Progressive Scan CMOS
Min. Illumination	0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Speed	1/3 s to 1/10,000 s
Lens	2.8mm，Angle of view：106 �
Lens Mount	φM12
Day & Night	IR cut filter with auto switch
DNR	3D DNR
Wide Dynamic Range	120dB
Angle Adjustment	Pan: -30�~ 30�, Tilt: 0 ~ 75�, Rotation: 0 ~ 360�
Compression Standard
Video Compression	H.264 / MJPEG / H.264 Zip+
H.264 Type	Main Profile
Video Bit Rate	32Kbps ~ 16Mbps
Dual Streams	Support
Audio Compression	G.711 / G.722.1 / G.726 / MP2L2
Audio Bit rate	64Kbps (G.711) / 16Kbps (G.722.1) / 16Kbps (G.726) / 32-128 Kbps (MP2L2)
Max. Resolution	2688�1520
Frame Rate	60Hz: 20fps(2688�1520), 30fps(1920�1080), 30fps(1280�720) 50Hz: 20fps(2688�1520), 25fps(1920�1080), 25fps(1280�720)
Image Setting	Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
BLC	Support, zone configurable
ROI Codec	Support
Network
Network Storage	NAS (Support NFS,SMB/CIFS), ANR
Alarm Trigger	Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception
Protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
General	One-key reset, Flash- prevention, duals tream, heartbeat, mirror, password protection,privacy mask, watermark, IP address filtering, Anonymous access
Standard	ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI
Interface
Communication Interface	1 RJ45 10M / 100M Ethernet port
On-board Storage	Built-in Micro SD/SDHC/SDXC slot, up to 128GB
On-board storage	Yes
Alarm interface	1 x alarm I/O
Audio interface	Built-in microphone and 1 x audio output
Reset	Yes
Wi-Fi
Wireless Standards	IEEE802.11b, 802.11g, 802.11n
Frequency Range	2.4 GHz ~ 2.4835 GHz
Channel Bandwidth	20/40M Hz Support
Protocols	802.11b: CCK, QPSK, BPSK, 802 .11g/n: OFDM
Security	64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transfer Rates	11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps
Wireless Range	50 meters *The performance varies based on actual environment.
General
Working Temperature /Humidity	-22�F ~ 140�F (-30�C ~ 60�C) Humidity 95% or less (non-condensing)
Power Supply	DC12V �25%, PoE (802.3af)
Power Consumption	Max. 5W
IR Range	Approx. 33ft (10 meters )
Material	Top Cover: Plastic; Base: Metal
Weather Proof Ratings	IP67
Impact Protection	IEC60068-2-75Eh, 20J; EN50102, up to IK08
Dimensions	3.9"x3.8"x2.1" (99.3x96.7x52.8 mm)
Weight	1.32 lbs (600 g)
