LTS CMIP183 1.3 Megapixel Spy Micro IP Camera 2.8mm Fixed Lens

Additional View

LTS CMIP183 1.3 Megapixel Spy Micro IP Camera 2.8mm Fixed Lens

1280 x 960 high resolution
120dB WDR
ROI codec
On-board storage, up to 64GB
Triple video streams
Rotate mode
Audio/Alarm IO

Model	CMIP183
Camera
Image Sensor?	1/3" sensor
Min. Illumination	Color: 0.01lux/F1.2, AGC on B/W: 0.001lux/F1.2, AGC on
Shutter Speed	1s ~ 1/100,000s
Slow Shutter	Support
Lens	2.8mm @ F2.0, angle of view: 73.1 ?
Lens Mount	M12
Day & Night	Electronic
Digital Noise Reduction	3D DNR
Wide Dynamic Range	120dB
Compression Standard
Video Compression	H.264 / MPEG4 / MJPEG
H.264 Type	Baseline Profile / Main Profile / High Profile
Bit Rate	32 Kbps ? 16 Mbps
Audio Compression	G.711/G.726
Audio Bit Rate	64Kbps(G.711) / 16Kbps(G.726)
Max. Resolution	1280 ? 960
Frame Rate	60Hz: 30fps (1280 ? 960), 30fps (1280 ? 720) 50Hz: 25fps(1280 ? 960), 25fps (1280 ? 720)
Third Stream	Independent with Main Stream and Sub Stream, up to 60Hz: 30fps (1280 ? 960) 50Hz: 25fps(1280 ? 960)
BLC	Support, zone optional
HLC	Support
Image Settings	Rotate mode, Saturation, Brightness, Contrast, Sharpness, Grayscale adjustable by client software or web browser
Day/night mode	Auto/Schedule/Triggered by Alarm In
ROI	Max. 4 ROI areas
Picture Overlay	128 x 128, BMP 24bit, zone configurable
Network
Network Storage	NAS
Alarm Trigger	Motion detection, audio detection, face detection, dynamic analytic, tampering alarm, network disconnect, IP address conflict, storage exception, storage error
Protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour (SIP optional)
System compatibility	ONVIF, PSIA, CGI
Security	Reset, flickerless, 3 streams, hearbeat, mirror, user authentication, video masking, watermark, anonymous log on, IP address filtering
Interface
Audio	3.5mm Audio In (Mic in/Line in) / Line out
Communication Interface	1 x RJ45 10M/100M Ethernet port, 1 x RS232
Alarm I/O	1
Video Output	1 x RJ12 interface
On-board storage	Built-in Micro SD/SDXC slot, up to 64 GB
General
Working Temperature /Humidity	-22 ?F ~ 140 ?F(-30 ?C ~ 60 ?C ) Humidity 95% or less (non-condensing)
Power Supply	DC12V?10% / PoE(802.3af)
Power Consumption	Max. 6.5W
Dimension?	3.1"?4.1"?1.3"(78.0 ? 105.0 ? 32.0 mm)
Weight	1.0lb(450g)
