Surveillance Mega-Store Ultimate Destination for All CCTV Needs
IP68 WEATHER RATEDConstant exposure to the elements is tough on any camera. Because the BZ series is IP68 weather rated, you no longer need to worry about adverse weather conditions. |
HI INTENSITY IR LEDsOne IR LED on the new BZ Series Bullet outputs as much light as eight standard IR LEDs, and the focusing lenses help evenly distribute the infrared light. |
AUTOFOCUSAll BZ cameras have Motorized Zoom & Auto Focus. Use the CE-REMOTE to set the focal length, and the autofocus lens will focus the scene to perfection. |
EASY INSTALLATIONBZ bullet cameras can be mounted to a variety of Conduit Boxes. Use the mounting hook to affix the camera in place and free both hands for screw fastening. |
EASY ADJUSTMENTSay goodbye to cumbersome brackets that require multiple set screws. Achieve any angle and lock the BZ camera in place with just one screw. |
DUAL VOLTAGE + RVMAll BZ Series Bullets are DC12V/AC24V and feature Rated Voltage Monitoring (RVM). The RVM LED indicator will illuminate to alert the installer of improper voltage. |
- 1/2.8" SONY Starvis 2.13 Megapixel CMOS Sensor
- 1080p @ 30fps Over RG59 Coax
- 2.8~8mm (ƒ1.6) True D/N Autofocus Lens
- 4 High Intensity IR LEDs
- EX-SDI 2.0 / HD-SDI & Analog option
- EXHD Lite 2.0 DSP
- OSD Menu Control via CE-REMOTE or UCC* (CE-REMOTE required for Zoom/Focus Adjustments)
- RVM (Rated Voltage Monitoring)
- DC12V/AC24V
- IP68 Weather Rated
Model | CE-BZ0HDBL |
Camera | |
Image Sensor | 1/2.8" SONY Starvis 2.13 Megapixel CMOS Sensor |
Resolution | 1080p |
Effective Pixels | 1944 (H) x 1092 (V) |
Scanning System | Progressive Scan |
S/N Ratio | More than 52dB (AGC Off) |
Frame Rate | 1080p: 30 FPS 720p: 30 FPS |
Minimum Illumination | Color: 1 Lux (Sens-Up x32) Black and White: 0.1 Lux (Sens-Up x32) |
Shutter Speed | 1/30 - 1/60,000 sec. / AUTO |
Lens | |
Type | Motorized Vari-Focal Auto-Focusing |
Focal Range | 2.8~8mm |
Max. Aperture Ratio | ƒ1.6 |
Field Of View | 114.2° ~ 54.7° (Horizontal) |
IR LEDs | |
Quantity | 4 High Intensity IR LEDs |
DSP | |
DSP Version | EXHD Lite 2.0 |
Menu Control | |
DIN Port | For use with CE-REMOTE (*CE-REMOTE required for Zoom/Focus Adjustments) |
Connections | |
HD Video Output | 1 BNC Output (HD-SDI, EX-SDI 2.0) |
Composite Video Output | 1 BNC Output |
Remote Control Input | 1 DIN Input |
Power Requirements | |
Type | DC12V and AC24V |
Power Consumption | DC12V: 10.2 Watts (0.85 Amp) AC24V: 7.2 Watts (0.3 Amp) |
Physical | |
Product Dimensions | 9.25" (L) x 5.25" (H) 234.95mm (L) x 133.35mm (H) |
Product Weight | 2.35 lbs (1065.942 g) |
Materials | |
Housing | Aluminum |
Environmental | |
Weather Rating | IP68 |
Operating Temperature | -40° to 122° F (-40° to 50° C) |
Operating Humidity | 0% to 95% RH |
What’s Included | |
Mounting Plate 4 Phillips Screws (M5x25) 4 Allen Bolts (M4x8) 4 Plastic Washers 4 Drywall Anchors Foam Gasket 3mm Allen Wrench 5mm Allen Wrench | |
Warranty & Support | |
Warranty | 3 Year Warranty w/1st Year Advance Replacement |
Technical Support | Free Lifetime Technical Support via Phone (1-800-549-6393) |
